Cisco ASR 903 Hardware Installation Guide

Example: Configuration with A900-RSP3-200-S with Blank Deflector (A900-IMA-BLNK-DEF)
In the below configuration, the overall operating temperature of the router is enhanced by using
A900-IMA-BLNK-DEF in the slots above A900-IMA8Z interface module. The maximum operating temperature
of the router is enhanced from 55°C to 65°C by using A900-IMA-BLNK-DEF in slots 1 and 5 (above
A900-IMA8Z).
To support 65°C ambient temperature, EXT optics need to be used for 10G ports.Note
A903-FAN-EA900-RSP3C-200A900-IMA-BLNK-DEF
A900-IMA8Z
A900-RSP3C-200A900-IMA-8T1Z
A900-IMA-8T1Z
PSUPSUA900-IMA-BLNK-DEF
A900-IMA8Z
Temperature Sensor
The Cisco ASR 903 Router has a temperature sensor to detect overtemperature conditions inside the chassis.
Temperature Sensors on the A900 RSP1 and A900 RSP2 modules
The overtemperature detection trips at 75 degrees C +/- 5% with the ambient (inlet) trip point at 67 degrees
C. This condition is reported to the processor as an interrupt, and the software takes action to generate the
appropriate alarms.
Temperature Sensors on the A900 RSP3 modules
The maximum operating temperature of RSP3 module and the interface modules is less than the maximum
operating temperature of the Cisco ASR 903 router. The IOS software decides the appropriate temperature
thresholds to generate warnings, and shuts down the system when abnormally high temperature is detected.
For more information, see Maximum Operating Ambient Temperature Support for RSP3 Modules.
Cisco ASR 903 Aggregation Services Router Hardware Installation Guide
48
Cisco ASR 903 Router Overview
Temperature Sensor
