CHAPTER 3
Power Supply Installation
This chapter applies only to the Catalyst 2960-XR switches. It contains these topics:
Power Supply Module Overview, page 53
Installation Guidelines, page 56
Installing or Replacing an AC Power Supply, page 57
Finding the Serial Number, page 59
Power Supply Module Overview
The switch operates with either one or two active power supply modules. You can use two AC modules, or
one module and a blank cover.
The Catalyst 2960XR-48FPD-I and 2960XR-48FPS-I only support the PWR-C2-1025WAC power supply.
You cannot use the PWR-C2-250WAC and PWR-C2-640WAC power supplies in these switches.
Note
Table 16: Power Supply Model Numbers and Description
DescriptionPart Number
250-W AC power supply modulePWR-C2-250WAC=
640-W AC power supply modulePWR-C2-640WAC=
1025-W AC power supply modulePWR-C2-1025WAC=
The 250-W and 640-W AC power supply modules are autoranging units that support input voltages between
100 and 240 VAC. The 1025-W power supply module is an autoranging unit that supports input voltages
between 115 and 240 VAC. All power supply modules have internal fans. All switches ship with a blank
cover in the second power supply slot.
Catalyst 2960-X and 2960-XR Switch Hardware Installation Guide
OL-28309-02 53
