Cisco Catalyst 9124AX Series User Manual

CONTENTS
Preface vii
PREFACE
About this Guide vii
Conventions vii
Related Documentation viii
Communications, Services, and Additional Information viii
Cisco Bug Search Tool viii
About the Cisco Catalyst 9124AX Series Outdoor Access Point 1
CHAPTER 1
Introduction to Cisco Catalyst 9124AX Series Outdoor Access Point 1
Cisco Catalyst 9124AX Series Outdoor Access Point Features 1
AP Model Numbers and Regulatory Domains 3
Antennas and Radios 4
Hardware Features 7
CHAPTER 2
Access Point Views, Ports, and Connectors 7
Connectors and Ports on the AP 7
C9124AXI (Internal Antenna) Model: Antenna Radiation Patterns 11
C9124AXD (Directional Antenna) Model: Antenna Radiation Patterns 14
C9124AXE (External Antenna) Model: Antenna Radiation Patterns 17
Supported External Antennas 23
Power Sources 26
Power Injectors 26
Ethernet (PoE) Ports 27
Unpacking Your Access Point 29
CHAPTER 3
Package Contents 29
Cisco Catalyst 9124AX Series Outdoor Access Point Hardware Installation Guide
iii

Cisco Catalyst 9124AX Series Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Frequency Bands	2.4 GHz, 5 GHz
MIMO	4x4
IP Rating	IP67
Spatial Streams	4
Power Options	802.3at PoE+, DC power adapter
Radios	Dual Radio (2.4 GHz and 5 GHz)
Antenna	Internal
Power over Ethernet	Yes
Mounting	Wall, ceiling, pole
Weight	1.2 kg
Security	WPA3, WPA2, WPA
Management	Cisco DNA Center, CLI, WebUI
Ethernet Ports	1 x 10/100/1000/2500 Multigigabit Ethernet (RJ-45)
Dimensions	220 x 220 x 66 mm
