Connectors and Ports on the Sides
Figure 4: Models C9124AXI, C9124AXD, and C9124AXE Left–Side and Right–Side Connectors and Ports
Console Port1
Grounding Pad2
DC Power In3
C9124AXI(InternalAntenna)Model:AntennaRadiationPatterns
The following illustrations show the C9124AXI model with internal antenna radiation patterns:
