Cisco Catalyst 9124AX Series - C9124 AXD (Directional Antenna) Model: Antenna Radiation Patterns

Figure 14: C9124AXI–AUX RF ASIC Antenna Radiation Pattern (5–GHz
Elevation)
Figure 13: C9124AXI–AUX RF ASIC Antenna Radiation Pattern
(5–GHz Azimuth)
C9124AXD (Directional Antenna) Model: Antenna Radiation
Patterns
The C9124AXD model with directional internal antenna has its radio radiation patterns shown in the following
images:
Cisco Catalyst 9124AX Series Outdoor Access Point Hardware Installation Guide
14
Hardware Features
C9124AXD (Directional Antenna) Model: Antenna Radiation Patterns
