When you are installing a Layer 3 AP on a different subnet than the controller, ensure the following:
• Ensure that a DHCP server is reachable from the subnet on which you want to install the AP.
• The subnet has a route back to the controller and ensure that the route back to the controller
has the destination UDP ports 5246 and 5247 open for CAPWAP communications.
• Ensure that the route back to the primary, secondary, and tertiary controllers allows IP packet
fragments.
• Ensure that the AP and the controller have a static 1-to-1 NAT to an outside address if address
translation is used. (Port Address Translation is not supported.).
Note
Mounting the Access Point
This section provides instructions to mount the AP. Personnel mounting the AP must have knowledge of the
wireless AP, bridging techniques, and grounding methods.
Choosing a Mounting Kit
You can mount the AP in one of the following configurations that best fits installation application:
• Vertically mounted to a wall or pole.
• Horizontally mounted to an eave, ceiling, or pole.
• On a cable strand
The following table shows the typical mount used for each AP model.
Note
Purpose9124AXE9124AXD9124AXIAP Mounting Kit
4
Fixed mounting kit for vertical mounting
on wall and for pole of diameter 2 to 5 inch
(51 to 127 mm). See:
Vertically Mounting the AP to a Wall, on
page 40
Vertically Mounting the AP to a Pole, on
page 42
YYN
AIR-MNT-VERT1=
Cisco Catalyst 9124AX Series Outdoor Access Point Hardware Installation Guide
38
Installation Overview
Mounting the Access Point
