Antenna NameAntenna Gain
(dBi)
PID
Cisco Aironet Dual-Band Omnidirectional Colinear Array
(Gray), Self-Identifying Antenna
Connectors: N-Male
74AIR-ANT2547VG-NS
Cisco Aironet 2.4–GHz/5–GHz 8–dBi 3-Element Dual
Polarized Patch Antenna
Connectors: N-Female Bulkhead x3
88AIR-ANT2588P3M-N=
Cisco Aironet 2.4–GHz/5–GHz 8–dBi 4-Element
Dual-Polarized Patch Self-Identifying Antenna
Connectors: N-Female Bulkhead
88AIR-ANT2588P4M-NS=
Cisco Aironet 5–dBi Omnidirectional Antenna—5AIR-ANT2450V-N=
Cisco Aironet 8–dBi Omnidirectional Antenna—8AIR-ANT2480V-N=
Cisco Aironet 2.4–GHz 13–dBi Directional Antenna—13AIR-ANT2413P2M-N=
Cisco Aironet 2.4–GHz 13–dBi Directional Antenna,
Self-Identifying
—13AIR-ANT2413P2M-NS=
Cisco Aironet 8–dBi Omnidirectional Antenna8—AIR-ANT5180V-N=
Cisco Aironet 5–GHz 14–dBi Directional Antenna14—AIR-ANT5114P2M-N=
Cisco Aironet 5–GHz 14–dBi Directional Antenna,
Self-Identifying
14—AIR-ANT5114P2M-NS=
Cisco Aironet Dual-Band Omnidirectional Antenna86AIR-ANT2568VG-N
Cisco Aironet Dual-Band Omnidirectional Antenna,
Self-Identifying
86AIR-ANT2568VG-NS
Cisco Aironet Four-Port Dual-Band Polarization-Diverse Array
Antenna
1313AIR-ANT2513P4M-N=
Cisco Aironet Four-Port Dual-Band Polarization-Diverse
ArrayAntenna, Self-Identifying
1313AIR-ANT2513P4M-NS=
For installation instructions and detailed information on any of these antennas, refer to the antenna guide at:
http://www.cisco.com/c/en/us/support/wireless/aironet-antennas-accessories/
products-installation-guides-list.html
Follow all safety precautions when installing the antennas. For information on safety, see Safety Precautions
when Installing Antennas, on page 93.
