• AP-mounting brackets to mount the C9124AXI or C9124AXD AP.
DescriptionMounting Brackets
Vertical mount to a wall or 2 to 5 inch (51 to 127 mm) diameter poleAIR-MNT-VERT1=
Articulating mount to a wall or 2 to 5 inch (51 to 127 mm) diameter poleAIR-MNT-ART1=
Vertical mount with DC adapter to a wall or 2 to 5 inch (51 to 127 mm) diameter
pole
AIR-MNT-VERT2=
Horizontal mount to a wall or 2 to 5 inch (51 to 127 mm) diameter poleAIR-MNT-HORZ1=
Optional for AIR-MNT-HORZ1= kit to mount DC power supplyAIR-ACC-PS-MNT1
Cable strand horizontal mountAIR-MNT-STRAND1=
• Accessory kits
DescriptionAccessory Kit
Gland kit for SFP port (Qty: 5)AIR-SFP-KIT1=
AP paintable coverC9124-CVR1=
This kit contains the following items:
• CAT 5e RJ45 Ethernet port plug and gland assembly (Qty:
5)
• RJ45 port dust caps (Qty: 2)
• Ground lug (Qty: 1)
• DC plug (Qty 1)
AIR-ACC-KIT1=
Lightning Arrestor kitAIR-ACC245LA-N=
CAT 6/6A Ethernet connector and cable gland assembly. Qty:
5
AIR-ACC-CAT6=
• Power injectors when PoE is not available.
DescriptionPower Supply
60W rated outdoor power injector, with North America AC plugAIR-PWRINJ-60RGD1=
60W rated outdoor power injector, global version without AC plugAIR-PWRINJ-60RGD2=
30W rated single-port PoE injectorAIR-PWRINJ6=
Cisco Catalyst 9124AX Series Outdoor Access Point Hardware Installation Guide
31
Unpacking Your Access Point
Cisco Orderable Accessories

Cisco Catalyst 9124AX Series Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Frequency Bands	2.4 GHz, 5 GHz
MIMO	4x4
IP Rating	IP67
Spatial Streams	4
Power Options	802.3at PoE+, DC power adapter
Radios	Dual Radio (2.4 GHz and 5 GHz)
Antenna	Internal
Power over Ethernet	Yes
Mounting	Wall, ceiling, pole
Weight	1.2 kg
Security	WPA3, WPA2, WPA
Management	Cisco DNA Center, CLI, WebUI
Ethernet Ports	1 x 10/100/1000/2500 Multigigabit Ethernet (RJ-45)
Dimensions	220 x 220 x 66 mm
