Cisco Catalyst 9800-L Series User Manual

CHAPTER 3
Installing the Cisco Catalyst 9800-L Wireless
Controller
This chapter describes how to install the Cisco Catalyst 9800-L Wireless Controller.
IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work
on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard
practices for preventing accidents. Use the statement number provided at the end of each warning to locate
its translation in the translated safety warnings that accompanied this device. Statement 1071
Warning
SAVE THESE INSTRUCTIONS
• Mounting the Controller, on page 13
• Connecting the Controller Console Port, on page 24
• Management Ethernet Port Cable Connection, on page 24
• Installing a Security Lock, on page 25
Mounting the Controller
This section describes the various mounting options for the controller:
Mounting the Controller on Desktop or Shelf
Before mounting the controller on a desktop or shelf, install the rubber feet located in accessory kit shipped
with the controller.
To install the rubber feet to the controller, follow these steps:
Procedure
Step 1 Locate the rubber feet on the black adhesive strip that is shipped with the controller.
Cisco Catalyst 9800-L Wireless Controller Hardware Installation Guide
13

Cisco Catalyst 9800-L Series Specifications

General

Model	Cisco Catalyst 9800-L Series
Category	Controller
Throughput	5 Gbps
Redundancy	Yes
Form Factor	Rack-mountable
Redundant Power Supply	Optional
Power Supply	Internal
Operating System	Cisco IOS XE
Maximum Clients	2000
Management	Cisco DNA Center, CLI, WebUI
Wireless Standard	802.11ax
Management Port	RJ-45
Operating Temperature	0 to 40°C
Input Voltage	100-240 VAC, 50/60 Hz
Ports	4 x 10G SFP+
