Cisco Catalyst IR1800 Rugged Series - Installing a PIM

Figure 14: Sim Access Plate
Step 4 Install your sims as shown in the following graphic. Make note of the proper slot number and sim orientation.
Figure 15: Sim Installation
DescriptionItem
Micro
SIMs
1
SIM 02
