Cisco cBR Series Configuration Guide

PurposeCommand or Action
Sets the upstream channel or channels to which
the DSG 1.2 tunnel applies.
cabledsg tggroup-id [channel channel-id
[ucid ID1 ]]
Example:
Router(config)# cable dsg tg 1 channel
1 ucid 1
Step 4
Sets the vendor-specific parameters for upstream
DSG 1.2 channels.
cable dsg tg group-id [channel channel-id
[vendor-param vendor-group-id ]]
Example:
Router(config)# cable dsg tg 1 channel
1 vendor-param 1
Step 5
Configures vendor-specific parameters for A-DSG
1.2. To remove this configuration from the Cisco
CMTS, use the no form of this command.
cable dsg vendor-param group-id vendor
vendor-index oui oui value value-in-TLV
Example:
Router(config)# cable dsg vendor-param
1 vendor 1 oui ABCDEA value 0101AB
Step 6
Configures the A-DSG 1.2 downstream channel
list. The channel list is a list of DSG channels
cable dsg chan-list list-index index
entry-index freq freq
Step 7
(downstream frequencies) that set-top boxes can
Example:
Router(config)# cable dsg chan-list 1
index 1 freq 47000000
search to find the DSG tunnel appropriate for their
operation. To remove the A-DSG 1.2 channel list
from the Cisco CMTS, us the no form of this
command.
Configures the A-DSG 1.2 timer entry to be
associated to the downstream channel, and
cable dsg timer inde [Tdsg1 Tdsg1 ] | [
Tdsg2 Tdsg2 ] | [Tdsg3 Tdsg3 ] | [ Tdsg4
Tdsg4 ]
Step 8
encoded into the Downstream Channel Descriptor
(DCD) message. To remove the cable DSG timer
Example:
Router(config)# cable dsg timer 1 Tdsg1
1 Tdsg2 2 Tdsg3 3 Tdsg4 4
from the Cisco CMTS, use the no form of this
command.
Returns to privileged EXEC mode.end
Example:
Router(config)# end
Step 9
What to Do Next
Troubleshooting Tips
Refer to debug and show commands in the How to Monitor and Debug the Advanced-mode DOCSIS Set-Top
Gateway Feature, on page 29.
Cisco cBR Series Converged Broadband Routers Application—Voice and Video Configuration Guide
16
Advanced-Mode DOCSIS Set-Top Gateway 1.2 for the Cisco CMTS Routers
Configuring Global Tunnel Group Settings for Advanced-Mode DSG 1.2
