Cisco cBR Series Configuration Guide

Procedure
Step 1
Cut and paste the scope selection tag create commands from the scripts into the nrcmd> command line.
These names have to be exactly as they appear in the scripts.Note
Step 2
Then attach the selection tags to the appropriate scripts:
Example:
CM_Scope tagCablemodem
PC_Scope tagComputer
Telco Return for the Cisco cBR-8 Router
Before You Begin
If you are using the prepacketencode and postclientlookup .tcl scripts for telco return, the telco return
scope does not have a selection tag associated to the scope.
Note
Procedure
Step 1
Put the tag Telcocablemodem on the primary cable interface scope to pull addresses from that pool instead.
Step 2
Follow the same procedure as above, but use a telco return policy which has a different .cm file with
telco-specific commands in it.
Creating Network Scopes
Following is an example for creating scopes for your network. This example assumes two Cisco cBR-8
converged broadband routers in two locations, with one cable interface card on one Cisco cBR-8 configured
for telco return.
cm-toledo1_2-0 10.2.0.0 255.255.0.0 assignable 10.2.0.10-10.2.254.254 tagCablemodem
tagTelcomodem Default GW=10.2.0.1 (assigned by scripts)
cm-toledo1_3-0 10.3.0.0 255.255.0.0 assignable 10.3.0.10-10.3.254.254 tagCablemodem
tagTelcomodem Default GW=10.3.0.1 (assigned by scripts)
pc-toledo1_2-0 208.16.182.0 255.255.255.248 assignable 208.16.182.2-208.16.182.6 tagComputer
Default GW=208.16.182.1 (assigned by scripts)
pc-toledo1_3-0 208.16.182.8 255.255.255.248 assignable 208.16.182.10-208.16.182.14 tagComputer
Default GW=208.16.182.9 (assigned by scripts)
telco_return_2-0 192.168.1.0 255.255.255.0 (No assignable addresses, tag was put on cable
modem primary scope to force telco-return cable modem to pull address from primary scope)
cm-arlington1_2-0 10.4.0.0 255.255.0.0 assignable 10.4.0.10-10.4.254.254 tagCablemodem
Default GW=10.4.0.1 (assigned by scripts)
cm-arlington1_3-0 10.5.0.0 255.255.0.0 assignable 10.5.0.10-10.5.254.254 tagCablemodem
Default GW=10.5.0.1 (assigned by scripts)
Cisco cBR Series Converged Broadband Routers Application—Voice and Video Configuration Guide
49
Cisco Network Registrar for the Cisco CMTS Routers
Telco Return for the Cisco cBR-8 Router
