Cisco cBR Series Configuration Guide

Configuring WAN Interfaces for Multicast Operations
In addition to basic WAN interface configuration on the Cisco CMTS, described in other documents, the
following WAN interface commands should be configured on the Cisco CMTS to support IP multicast
operations with A-DSG 1.2, as required.
•
ip pim
•
ip pim ssm
•
ip cef
These commands are described in the Configuring IP Multicast Operations, on page 20, and in the following
documents on Cisco.com.
For additional information about the ip pim command, refer to the following document on Cisco.com:
•
Cisco IOS IP Command Reference, Volume 3 of 4 : Multicast, Release 12.3
http://www.cisco.com/en/US/docs/ios/12_3/ipmulti/command/reference/iprmc_r.html
For additional information about the ip pim ssm command, refer to the following document on Cisco.com:
•
Cisco IOS IP Command Reference, Volume 3 of 4: Multicast , Release 12.3 T
http://www.cisco.com/en/US/docs/ios/12_3t/ip_mcast/command/reference/ip3_i2gt.html
For additional information about the ip cef command, refer to the following document on Cisco.com:
•
Cisco IOS Switching Services Command Reference , Release 12.3
http://www.cisco.com/en/US/docs/ios/12_3/switch/command/reference/swtch_r.html
Configuring a Standard IP Access List for Packet Filtering
This section describes how to configure a standard IP access list so that only authorized traffic is allowed on
the cable interface.
This procedure assumes a basic knowledge of how access lists use an IP address and bitmask to determine
the range of IP addresses that are allowed access. For full details on configuring access lists, see the
documents listed in the Additional References, on page 35.
Tip
Procedure
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Router# configure terminal
Step 1
Cisco cBR Series Converged Broadband Routers Application—Voice and Video Configuration Guide
25
Advanced-Mode DOCSIS Set-Top Gateway 1.2 for the Cisco CMTS Routers
Configuring WAN Interfaces for Multicast Operations
