If you are using the flexible mount with a direct-wired junction box (CDB-MNT-FLEX-DIR), refer to the
Electrical Installation section before you start the installation procedure.
Note
Before You Begin
•
Refer to Installation Guidelines section.
•
Refer to Electrical Installation section if you are using the flexible mount with direct-wired junction box
(CDB-MNT-FLEX-DIR).
•
Review the following illustrations and tables.
Figure 29: Mounting Bracket Detail
1/4" hole for attaching to strut1
3/8" hole for attaching to strut2
Mounting screw holes3
Catalyst Digital Building Series Switch Hardware Installation Guide
43
Switch Installation
Flexible Mounting
