Figure 30: Strut Channel Nut Attachment Detail
Strut channel nut1
U-shaped mounting bracket2
Bolt matching the strut nut3
•
Strut channel nut slides is inserted into the channel and held by a spring or a plastic cone.
•
The bracket acts as an integrated washer. So, strut washer is not required.
•
Matching bolt is fed from below into the strut channel nut.
Catalyst Digital Building Series Switch Hardware Installation Guide
44
Switch Installation
Flexible Mounting
