Cisco Explorer Series User Manual

DHCTs with Single LED Indicators
734375 Rev H 123
Stage
POWER LED
Indicator
TV Monitor
Description
4
The light blinks once
every half-second.
If the DHCT cannot acquire the
CVT through a known good
QAM frequency, it scans the
recommended QAM
frequencies. The LED displays
FR.00 through FR.09 as the
DHCT checks each of the ten
recommended QAM
frequencies.
Go to stage 6 of this table.
5
The light blinks once
every half-second.
If the DHCT cannot acquire the
CVT through a recommended
QAM frequency, it 'hunts' until
it finds the frequency of a QAM
with a valid CVT table for that
DHCT. The [000] indicates the
QAM frequency.
6
The light blinks
twice, pauses, then
repeats.
The LED displays r.xxx, where
[xxx] indicates the number of
packets remaining to be
downloaded. This number
counts down to zero as the
packets are downloaded.
7
The light blinks 3
times, pauses, then
repeats.
CLr and PR.00 indicate that the
second part of the OS is installed
into flash memory.
Programs upper memory area
with ResApp.
8
The light is off.
The wave appears after the
DHCT resets to boot into the OS
and the newly downloaded
ResApp.

Cisco Explorer Series Specifications

General

Category	Media Converter
Series	Explorer
Model	Various (e.g., 4642HDC, 8642HDC, 9865HDC)
Type	Set-top box
Input Interfaces	CableCARD, Ethernet, USB
Output Interfaces	HDMI, Component, Composite, S-Video (depending on the model)
Video Resolution	Up to 1080p (depending on the model)
Audio Output	HDMI, Optical, RCA
Power Supply	External power adapter
Dimensions	Varies by model
Weight	Varies by model
