One 4-core Intel CPUProcessor
8-GB DDR4 DRAMMemory
8 GB (internal)Boot partition
Marvell SOHO 88E6390
First supported in Firepower Version 6.5 and ASA Version 9.13.
Note
L2 switch
One Gigabit Ethernet RJ-45 10/100/1000 BaseT
Restricted to network management access; connect with an RJ-45 cable
Management
port
One RJ-45
Use to access management through an external system
Console port
One USB Mini B
Use to access management through an external system
USB Mini B
port
One USB 3.0 Type A
Use to attach an external device such as storage
USB port
Eight Gigabit Ethernet RJ-45 10/100/1000 BaseT
Each RJ-45 (8P8C) copper port supports auto Medium Dependent Interface Crossover
(MDI/X) as well as auto-negotiation for interface speed, duplex, and other negotiated
parameters, and are MDI/X-compliant.
The ports are numbered (from top to bottom, left to right) 1, 2, 3, 4, 5, 6, 7, 8. Each port
includes a pair of LEDs, one each for connection status and link status. The ports are
named and numbered Gigabit Ethernet 1/1 through Gigabit Ethernet 1/8.
You can use ports 7 and 8 as PoE+ ports. PoE+ is first supported in Firepower
Version 6.5 and ASA Version 9.13.
Note
Network ports
Ports 7 and 8 are PoE+ ports; first supported in Firepower Version 6.5 and ASA
Version 9.13.
Note
PoE+ controller
card
Accepts a standard Kensington T-bar locking mechanism for securing the chassisLock slot
A small recessed button that if pressed for longer than three seconds resets the chassis to
its default state following the next reboot. Configuration variables are reset to factory
default, but the flash is not erased and no files are removed.
Reset button
No
System power is controlled by the power cord; there is no power button. To shut down
the Firepower 1010, remove the AC power supply.
Power switch
The chassis is powered on when you plug in the AC power supply.Power cord
socket
Cisco Firepower 1010 Hardware Installation Guide
3
Overview
Features
