Switch Installation
Installing the Switch
Figure 10 Attaching Brackets for 19-Inch Racks
1 Mid-mounting position 3 Cable-side mounting position
2 Phillips flat-head screws 4 Power-supply-side mounting position
208366
2
1
2
2
3
4
