69
Technical Specifications
Alarm Ratings
Alarm Ratings
Table 17 Technical Specifications for the PWR-RGD-AC-DC/IA Power-Supply Module
Power Specifications
Maximum output power 150 W
Nominal input voltage 100 to 240 VAC, 50 to 60 Hz
100 to 250 VDC
Absolute maximum (short term) input voltage 85 to 265 VAC, 47 to 63 Hz
88 to 300 VDC
Input current AC: 2.2 to 0.7 A, 85 to 265 VAC
DC: 2.5 to 0.6 A, 88 to 300 VDC
Total input BTU AC: 638 BTUs per hour
DC: 750 BTUs per hour
Table 18 Technical Specifications for the PWR-RGD-LOW-DC/IA Power-Supply Module
Power Specifications
Maximum output power 150 W
Nominal input voltage 24 to 60 VDC
Absolute maximum (short term) input voltage 18 to 75 VDC
Input current 12 to 2.5 A, 18 to 75 VDC
Total input BTU 737 BTUs per hour
Table 19 Alarm Input and Output Ratings
Alarm Ratings
Alarm input electrical specification 8 V @ 1mA
Alarm output electrical specification 30 V @ 1A
Note: The alarm output does not support AC voltage because the RJ-45 connector pin
spacing is too small.
