Cisco IE 3010 User Manual

31
Switch Installation
Installing the Switch
Attaching Brackets
Figure 20 Attaching 19-inch Rack Brackets
Attaching Brackets for IP-30 Compliance (Optional)
1. Insert the rubber plugs in the appropriate holes on both sides of the switch. See Figure 21 on page 32.
Note: The rubber plugs are not supplied with the switch. You can order a kit (part number IE-3010-IP30KIT)
containing the rubber plugs.
2. Use a screwdriver or pen to completely push in the rubber plugs. See Figure 12 on page 22.
3. Install the brackets on both sides of the switch. See Figure 22 on page 32.
1 Phillips truss-head screws
Cisco
Switch Series
IE 3010
208368
1
