Two number-10 wood screws (round- or pan-head) with number-10 washers or two number-10
washer-head screws, for mounting on a wall stud. The screws must be long enough to penetrate at least
3/4 inch (20 mm) into the supporting wood or metal wall stud.
•
Two number-10 wall anchors with washers, for mounting the router on a hollow wall.
•
Wire crimper for chassis grounding.
•
Wire for connecting the chassis to an earth ground.
•
Ethernet cables for connecting devices to the Ethernet ports.
•
Ratcheting torque flathead screwdriver that exerts up to 15 in-lb (1.69 N-m) of pressure.
•
A number-2 Phillips screwdriver.
Ethernet Devices
Identify the Ethernet devices that you will connect to the router: hub, servers, and workstations or PCs. Ensure
that each device has a network interface card (NIC) for connecting to Ethernet ports.
Installing the Router
This section describes how to install the Cisco 809 ISR. This router can be installed on a table top or other
flat horizontal surface, mounted on a wall, or DIN rail.
The recommended clearance when horizontally mounted is 1 inch on non-connector sides and 2 inches on
top. Stacking heat-dissipating objects on top of the router is not allowed. I/O side clearance is needed as it is
required to access the cable connections. Clearance is not required on the backside (opposite side from I/O
face) unless DIN rail mounting is required. Clearance is required to attach and mount the DIN rail bracket.
The same clearances apply when mounted vertically.
This section also describes how to attach external antennas to the routers
This equipment needs to be grounded. Use a green and yellow 14 to 18 AWG ground wire to connect the
host to earth ground during normal use. Statement 242
Warning
Accessing the SIM Cards
Two USIM sockets are provided with easy access via a secured panel on the back side of the router. The SIM
cards will be connected directly to the 4G radio.
This section describes how to install and/or replace a SIM card. Ensure that the router is not mounted to a
wall, floor, or DIN rail.
Do not touch any part of the exposed PCB circuit area when the SIM cover is removed.Caution
Cisco 809 Industrial Integrated Services Router Hardware Installation Guide
3
Installing the Router
Installing the Router
