Cisco IR829 Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Antennas
4G/LTE Case 3:
Front Panel Swivel
Mount 4G-LTE
dipoles
IR829GW-LTE
-GA-EK9
IR829GW-LTE
-GA-ZK9
IR829GW-LTE
-NA-AK9
IR829GW-LTE
-VZ-AK9
2x TNC(f)
None
—OR
qty 2x
PID: 4G-AE010-R
CPN: 07-1144-01
10ft extension base
for TNC dipole
antennas
—OR
qty 2x
PID: 4G-AE015-R
CPN: 07-1145-01
15ft extension base
for TNC dipole
antennas
None None Qty 2 x
4G Indoor Swivel
Mount Dipole, 0 dBi,
TNC(m), white
• 07-1174-01
• ANT-4G-DP-IN-TN
C
4G/LTE Case 4:
Front Panel Swivel
Mount 4G-LTE
dipoles
IR829GW-LTE
-GA-EK9
IR829GW-LTE
-GA-ZK9
IR829GW-LTE
-NA-AK9
IR829GW-LTE
-VZ-AK9
2x TNC(f)
None
—OR
qty 2x
PID: 4G-AE010-R
CPN: 07-1144-01
10ft extension base
for TNC dipole
antennas
—OR
qty 2x
PID: 4G-AE015-R
CPN: 07-1145-01
15ft extension base
for TNC dipole
antennas
None None Qty 2 x
4G Indoor Swivel
Mount Dipole, 0 dBi,
TNC(m), black
• 07-1137-01
• 4G-LTE-ANTM-D
Table 1-4 4G/LTE Radio Modules/Cables/Antennas
Use Case Radio Module Indoor Cable
Lightning
Arrestor or
Adapter Outdoor Cable Antenna
