Cisco IR829 Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Antennas
4G/LTE Case 5:
2x ceiling mount
4G-LTE antennas
IR829GW-LTE
-GA-EK9
IR829GW-LTE
-GA-ZK9
IR829GW-LTE
-NA-AK9
IR829GW-LTE
-VZ-AK9
2x TNC(f)
None None None Qty 2 x
4G Indoor
omni-directional
Ceiling Mount 2 dBi,
• 07-1121-01
• 4G-ANTM-OM-C
M
— OR
Qty 2 x
4G Dipole Ceiling
Mount 2 dBi
• 07-1174-01
• ANT-4G-DP-IP-TN
C
GPS Case 1:
GPS Antenna with
Integrated 15' coax
cable, Mounted to top
of Utility Cabinet
Roof
• SMA(f), qty 1
GPS Antenna.
Need one with
integrated coax cable
and SMA(m)
connector, 17ft,
outdoor, IP67
qty 1
• 07-1183-01
• GPS-ACT-ANTM-S
MA=
Table 1-4 4G/LTE Radio Modules/Cables/Antennas
Use Case Radio Module Indoor Cable
Lightning
Arrestor or
Adapter Outdoor Cable Antenna
