Cisco IR829 User Manual

1-14
Cisco IR829 Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Antennas
Table 1-5 lists the supported Single Band Cisco WiFi antenna for the Cisco IR829.
Ta b l e 1-5 Supported Single Band Cisco WiFi Antenna
Use Case Radio Module Indoor Cable
Lightning
Arrestor or
Adapter
Outdoor Cable Antenna
WiFi Use Case 2:
Single Band, Front
Panel Mounted
Antennas
Dual Band
Simultaneous
802.11n 2x2 MIMO
WiFi
Connectors:
4x RP-TNC (jack)
N/A N/A N/A 2x Single Band, Swivel
Mount Omni,
RP-TNC(plug), 2.2dBi @ 2.4
GHz
07-1056-02
AIR-ANT4941
2x Single Band, Swivel
Mount Omni,
RP-TNC(plug), 3.5dBi @ 5
GHz
• 07-1055-02
• AIR-ANT5135
WiFi Use Case 3:
Single Band,
Single Element,
Ceiling Mounted
Antennas
Dual Band
Simultaneous
802.11n 2x2 MIMO
WiFi
Connectors:
4x RP-TNC (jack)
None
— OR
RP-TNC (jack)
to RP-TNC
(plug), Outdoor
rated, Plenum
rated, 0.195"
O.D. cable,
5' long
• 37-1067-01
• AIR-CAB005
PL-R
N/A N/A 2x Single Band, Ceiling
Mount Omni, 36” LONG
RG-58 cable with RP-TNC
(plug), 5.2dBi @ 2.4 GHz
• 74-1868-01
• AIR-ANT1728
2x Single Band, Ceiling
Mount Omni, 36" LONG
RG-58 cable with RP-TNC
(plug), 5.2dBi @ 5 GHz
• 74-3733-01
• AIR-ANT5160V-R
WiFi Use Case 4:
2.4 GHz, Dual
Element, 5 GHz
Single Element,
Ceiling Mounted
Antennas
Dual Band
Simultaneous
802.11n 2x2 MIMO
WiFi
Connectors: 4x
RP-TNC (jack)
None
— OR
RP-TNC(jack) to
RP-TNC(plug),
Outdoor rated,
Plenum rated,
0.195” O.D.
cable, 5’ long
37-1067-01
AIR-CAB005PL
-R
N/A N/A 1x Single Band, Ceiling
Mount Omni, Dual Element,
36" LONG RG-58 cable with
RP-TNC, 2.0dBi @ 2.4 GHz
• 800-33316-01
• AIR-ANT24020V-R
2x Single Band, Ceiling
Mount Omni, 36" LONG
RG-58 cable with RP-TNC
(plug), 5.2dBi @ 5 GHz
• 74-3733-01
• AIR-ANT5160V-R

Cisco IR829 Specifications

General

Serial Interfaces	1 x RS-232
USB Ports	1 x USB 2.0
Wireless	802.11a/b/g/n
Product Type	Router
Form Factor	Rack-mountable
Connectivity Technology	Wired, Wireless
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
WAN Ports Qty	2
LAN Ports Qty	4
Cellular Protocol	LTE
Memory	2 GB DDR3
WAN Interfaces	2 x Gigabit Ethernet
LAN Interfaces	4 x 10/100/1000 Ethernet
Operating Temperature	-20 °C to 60 °C
Processor	1.2 GHz
