Cisco IR829 Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Antennas
WiFi Use Case 5:
Single Band, Dual
Element, Wall
Mounted Antennas
Dual Band
Simultaneous
802.11n 2x2 MIMO
WiFi
Connectors:
4x RP-TNC (jack)
None None
— OR
RP-TNC
lightning
arrestor,
qty 4
• 74-3722-
01
• AIR-AC
C245L
A-R
None
— OR
RP-TNC(plug) to
RP-TNC(jack)
LMR-400-DB, 5'
qty 4
• 37-0766-01
• AIR-CAB005LL
-R
— OR
RP-TNC(plug) to
RP-TNC(jack)
LMR-400-DB, 20'
qty 4
• 72-2760-02
• AIR-CAB020LL
-R
— OR
RP-TNC(plug) to
RP-TNC(jack)
LMR-400-DB, 50'
qty 4
• 72-2761-02
• AIR-CAB050LL
-R
— OR
RP-TNC(plug) to
RP-TNC(jack)
LMR-600-DB,
100'
qty 4
• 72-2766-02
• AIR-CAB100U
LL-R
1x Single Band, Dual
Element, Wall Mount Patch,
18" LONG RG-58 cable with
RP-TNC, 6.5dBi @ 2.4 GHz
• 800-27066-01
• AIR-ANT2465P-R
1x Single Band, Dual
Element, Wall Mount Omni,
18" LONG RG-58 cables
with RP-TNC, 4.5dBi @ 5
GHz (INDOOR ONLY)
• 800-25716-06
• AIR-ANT5145V-R
— OR
1x Single Band, Dual
Element, Wall Mount Patch,
18" LONG RG-58 cables
with RP-TNC, 7.0dBi @ 5
GHz (INDOOR/OUTDOOR)
• 800-25718-05
• AIR-ANT5170P-R
Table 1-5 Supported Single Band Cisco WiFi Antenna(continued)
Use Case Radio Module Indoor Cable
Lightning
Arrestor or
Adapter Outdoor Cable Antenna
