Cisco IR829 Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Antennas
Table 1-6 lists the supported Dual Band Cisco WiFi antenna for Cisco IR829.
WiFi Use Case 7:
Single Band, Dual
Element, Wall
Mounted Patch,
Indoor/ Outdoor
Antennas
Dual Band
Simultaneous
802.11n 2x2 MIMO
WiFi
Connectors:
4x RP-TNC (jack)
N(f) to
N(f),
RF-adapter
qty 4
• 29-1008
18-01
• AIR-AC
C370-
NF-N
F
RP-TNC(plug) to
N(m)-R/A
LMR-240-DB, 5'
qty 4
• 37-1492-01
• AIR-CAB005LL
-R-N
1x Single Band, Dual
Element, Wall Mount Patch,
18" LONG RG-58 cable with
N(m), 13dBi @ 2.4 GHz
• 07-1193-01
• AIR-ANT2413P2M-N
1x Single Band, Dual
Element, Wall Mount Patch,
18" LONG RG-58 cable with
N(m), 14dBi @ 5 GHz
• 07-1192-01
• AIR-ANT5114P2M-N
Table 1-5 Supported Single Band Cisco WiFi Antenna(continued)
Use Case Radio Module Indoor Cable
Lightning
Arrestor or
Adapter Outdoor Cable Antenna
Ta b l e 1-6 Supported Dual Band Cisco WiFi Antenna
Use Case Radio Module Indoor Cable
Lightning
Arrestor or
Adapter
Outdoor Cable Antenna
WiFi Use Case 8:
Dual Band Front
Panel Mounted
Antennas
Dual Band
Simultaneous
802.11n 2x2 MIMO
WiFi
Connectors:
2x RP-TNC (jack)
N/A N/A N/A 2x Dual Band, Swivel Mount
Omni, RP-TNC(plug), 2dBi
@ 2.4 GHz, 4dBi @ 5 GHz
• 07-1146-01
• AIR-ANT2524DB-R

Cisco IR829 Specifications

General

Serial Interfaces	1 x RS-232
USB Ports	1 x USB 2.0
Wireless	802.11a/b/g/n
Product Type	Router
Form Factor	Rack-mountable
Connectivity Technology	Wired, Wireless
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
WAN Ports Qty	2
LAN Ports Qty	4
Cellular Protocol	LTE
Memory	2 GB DDR3
WAN Interfaces	2 x Gigabit Ethernet
LAN Interfaces	4 x 10/100/1000 Ethernet
Operating Temperature	-20 °C to 60 °C
Processor	1.2 GHz
