Chapter 8 Configuring VLANs
VLAN Configuration Example
Table 8-2 shows the commands needed to configure the three VLANs in this example.
Table 8-3 shows the results of the configuration commands in Table 8-2. Use the show running
command to display the running configuration on the access point.
Ta b l e 8-2 Configuration Commands for VLAN Example
Configuring VLAN 1 Configuring VLAN 2 Configuring VLAN 3
router# configure terminal
router(config)# interface
dot11radio 0
router(config-if)# ssid boss
router(config-ssid)# vlan 01
router(config-ssid)# end
router# configure terminal
router(config)# interface
dot11radio
0
router(config-if)# ssid teach
router(config-ssid)# vlan 02
router(config-ssid)# end
router# configure terminal
router(config)# interface
dot11radio
0
router(config-if)# ssid learn
router(config-ssid)# vlan 03
router(config-ssid)# end
router configure terminal
router(config) interface
FastEthernet0.1
router(config-subif)
encapsulation dot1Q 1 native
router(config-subif) exit
router(config) interface
FastEthernet0.2
router(config-subif) encapsulation
dot1Q 2
router(config-subif) bridge-group 2
router(config-subif) exit
router(config) interface
FastEthernet0.3
router(config-subif) encapsulation
dot1Q 3
router(config-subif) bridge-group 3
router(config-subif) exit
router(config)# interface
Dot11Radio 0.1
router(config-subif)#
encapsulation dot1Q 1 native
router(config-subif)
bridge-group 1
router(config-subif)# exit
router(config) interface Dot11Radio
0.2
router(config-subif) encapsulation
dot1Q 2
router(config-subif) bridge-group 2
router(config-subif) exit
router(config) interface Dot11Radio
0.3
router(config-subif) encapsulation
dot1Q 3
router(config-subif) bridge-group 3
router(config-subif) exit
Ta b l e 8-3 Results of Example Configuration Commands
VLAN 1 Interfaces VLAN 2 Interfaces VLAN 3 Interfaces
interface Dot11Radio0.1
encapsulation dot1Q 1 native
no ip route-cache
no cdp enable
bridge-group 1
bridge-group 1
subscriber-loop-control
bridge-group 1
block-unknown-source
no bridge-group 1 source-learning
no bridge-group 1 unicast-flooding
bridge-group 1 spanning-disabled
interface Dot11Radio0.2
encapsulation dot1Q 2
no ip route-cache
no cdp enable
bridge-group 2
bridge-group 2
subscriber-loop-control
bridge-group 2
block-unknown-source
no bridge-group 2 source-learning
no bridge-group 2 unicast-flooding
bridge-group 2 spanning-disabled
interface Dot11Radio0.3
encapsulation dot1Q 3
no ip route-cache
bridge-group 3
bridge-group 3
subscriber-loop-control
bridge-group 3 block-unknown-source
no bridge-group 3 source-learning
no bridge-group 3 unicast-flooding
bridge-group 3 spanning-disabled
interface FastEthernet0.1
encapsulation dot1Q 1 native
no ip route-cache
bridge-group 1
no bridge-group 1 source-learning
bridge-group 1 spanning-disabled
interface FastEthernet0.2
encapsulation dot1Q 2
no ip route-cache
bridge-group 2
no bridge-group 2 source-learning
bridge-group 2 spanning-disabled
interface FastEthernet0.3
encapsulation dot1Q 3
no ip route-cache
bridge-group 3
no bridge-group 3 source-learning
bridge-group 3 spanning-disabled
