Switch Ports Off No link is detected on this port
Flashing orange (RJ45 ports only) Activity indicator
Solid green 1 Gbps link detected
In addition, there is a RESTORE button available on the front panel.
Insert a paperclip if a restore is required.
• A brief, momentary press: To delete a downloaded configuration and reboot.
• Press and hold for more than 10 sec: To force the unit into a full factory restore.
Back Panel Components
Function LED Status Meaning
Management Interface Green Connected, used for easy access to the local status page
Power Input N/A Power cords may be ordered separately.
Equipment is to be used only in a restricted access location and installed/operated only by trained service personnel.
