Item Function LED Status Meaning
1 Restore N/A Restore button to clear switch IP and local configuration settings
2 Management Interface Green Connected, used for easy access to the local status page
3 Stack Ports N/A Stack Cables are connected here
4 Redundant Fans Green Active and operational
5 Redundant Power Supplies Green Active and functional power supplies
Power cords may be ordered separately.
Package contents
In addition to the MS switch, the following are provided (mounting kit provided with 1U models only):
Rack Mount Kit includes:
▪ US 12-24 mounting screws and cage nuts, 5 of each
▪ INTL M5 mounting screws and cage nuts, 5 of each
▪ INTL M6 mounting screws and cage nuts, 5 of each
▪ Mounting washers
Equipment is to be used only in a restricted access location and installed/operated only by trained service personnel.
