Cisco Nexus 9504 - Weights and Quantities for the Chassis, Modules, Fan Trays, and Power Supplies

HeightDepthWidthChassis or Module
1.42 inches (3.61 cm)Inside chassis: 10.74
inches (27.28 cm)
Ejector levers outside
chassis: 0.75 inches (1.9
cm)
Without mounting
brackets: 6.81 inches
(17.3 cm)
With mounting brackets:
7.81 inches (19.84 cm)
System controller
modules
1.75 inches (4.4 cm)Inside chassis: 16.5 inches
(41.91 cm)
Ejector levers outside
chassis: 2.5 inches (6.35
cm)
17.0 inches (43.18 cm)Line cards
9.4 inches (23.88 cm)11.7 inches (29.72 cm)2.46 inches (6.25 cm)Fabric modules
Without mounting
brackets: 9.0 inches
(22.86 cm)
With mounting brackets:
10.6 inches (26.93 cm)
5.47 inches (13.9 cm)5.05 inches (12.81 cm)Fan trays
1.75 inches (4.4 cm)Inside chassis: 17.75
inches (44.96 cm)
Ejector levers outside
chassis: 0.75 inches (1.9
cm)
5.25 inches (13.33 cm)Power supply
Weights and Quantities for the Chassis, Modules, Fan Trays,
and Power Supplies
Weight per UnitComponent
84.0 lb (38.2 kg)Cisco Nexus 9504 Chassis (N9K-C9504)
—Supervisor Modules
4.84 lb (2.2 kg)
Supervisor A module (N9K-SUP-A)–
5.2 lb (2.37 kg)Supervisor A+ module (N9K-SUP-A+)–
6.0 lb (2.72 kg)Supervisor B module (N9K-SUP-B)–
5.3 lb (2.39 kg)Supervisor B+ module (N9K-SUP-B+)–
1.9 lb (0.9 kg)System Controller Modules (N9K-SC-A)
—Line cards that the N9K-C9504-FM fabric modules support
Cisco Nexus 9504 NX-OS Mode Switch Hardware Installation Guide
108
System Specifications
Weights and Quantities for the Chassis, Modules, Fan Trays, and Power Supplies
