Weight per UnitComponent
—Line cards that the N9K-C9504-FM-R fabric modules support
15.9 lb (7.2 kg)36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-RX)–
15.0 lb (6.8 kg)36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-R)–
12.43 lb (5.64 kg)36-port 40-Gigabit Ethernet QSFP+ line card (N9K-X9636Q-R)–
12.78 lb (5.8 kg)16-port 1/10-Gigabit SFP, 32-port 10/25-Gigabit Ethernet SFP, and 4-port
40/100-Gigabit Ethernet QSFP line card (N9K-X96136YC-R
–
—Fabric Modules
5.76 lb (2.6 kg)40-Gigabit N9K-C9504-FM fabric module–
6.6 lb (2.98 kg)100-Gigabit N9K-C9504-FM-E fabric module–
6.2 lb (2.8 kg)100-Gigabit N9K-C9504-FM-S fabric module supporting -S line cards–
6.2 lb (2.8 kg)100-Gigabit N9K-C9504-FM-R fabric module supporting -R and -RX line cards–
7.78 lb (3.53 kg)400-Gigabit N9K-C9504-FM-G fabric module–
—Fan Trays
7.6 lb (3.45 kg)
(N9K-C9504-FAN2)–
6.4 lb (2.9 kg)(N9K-C9504-FAN)–
—Power Supplies
5.9 lb (2.67 kg)
3-kW Universal AC/DC Power Supply (N9K-PUV-3000W-B)–
5.9 lb (2.67 kg)3.15-kW Dual Input Universal AC/DC Power Supply (N9K-PUV2-3000W-B)–
6.4 lb (2.9 kg)3-kW DC Power Supply (N9K-PDC-3000W-B)–
6.2 lb (2.8 kg)3-kW AC Power Supply (N9K-PAC-3000W-B)–
Power Specifications
Power specifications include the specifications for each type of power supply module.
Power Requirements for Switch Modules
Determine the number of power supplies required to operate all the modules in a switch by adding the maximum
power amounts for each module in the switch. Then divide the sum by 3000 W. If there is a fractional amount
in the result, add 1 to the result. For n+1 redundancy, add one more power supply. For n+n redundancy, double
the number of power supplies and provision for a second power source.
To determine the typical consumption, add the typical power amounts for each module in the switch.
Cisco Nexus 9504 NX-OS Mode Switch Hardware Installation Guide
110
System Specifications
Power Specifications
