MaximumTypicalComponent
684 W346 W48-port 10-Gigabit Ethernet SFP+ and 4-port 100-Gigabit Ethernet QSFP28 line card
(N9K-X9788TC-FX)
–
792 W632 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9736C-EX)–
900 W607 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9736C-FX)–
684 W571 W36-port 40-Gigabit Ethernet QSFP28 line card (N9K-X9736Q-FX)–
720 W430 W32-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9732C-EX)–
840 W520 W32-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9732C-FX)–
504 W270 WLine cards that are supported by N9K-C9504-FM-G fabric modules
900 W607 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9736C-FX)–
516 W415 W48-port 1/10/25-Gigabit Ethernet SFP28 and 4-port 40/100-Gigabit Ethernet QSFP28 line
card (N9K-X97160YC-EX)
–
684 W346 W48-port 1/100 BASE-T and 4-port 100-Gigabit Ethernet QSFP28 line card
(N9K-X9788TC-FX)
–
1680 W650 W16-port 400-Gigabit Ethernet QSFP-DD line card (N9K-X9716D-GX)–
251 W171 WLine cards that are supported by N9K-C9504-FM-S fabric modules
504 W440 W32-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9432C-S)–
130 W140 WLine cards that are supported by N9K-C9504-FM-R fabric modules
902 W650 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-R)–
456 W329 W36-port 40-Gigabit Ethernet QSFP28 line card (N9K-X9636Q-R)–
300 W213 W16-port 1/10-Gigabit SFP, 32-port 10/25-Gigabit Ethernet SFP, and 4-port 40/100-Gigabit
Ethernet QSFP line card (N9K-X96136YC-R
–
1100 W800 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-RX) with TCAM–
——Fan Trays
129 W95W(N9K-C9504-FAN)–
600 W105 W(N9K-C9504-FAN2)–
For example, to determine the maximum amount of power that your fully loaded switch consumes, add the maximum
power consumption of two supervisor B modules (2 x 90 W = 180 W), two system controllers (2 x 26 W = 52 W), four
48-port 100-Gigabit line cards (4 x 1050 W = 4200 W), six fabric modules (6 x 504 W = 3024 W), and three fan trays
(3 x 600 W = 1800 W). The total is 9,256 W.
Step 2 Determine the number of power supplies required to power the modules that are installed in the switch by dividing the
module power requirement amount (see Step 1) by the output wattage (3000 W) of the power supplies installed in the
switch. Round up the fractional result to the nearest ones digit.
Cisco Nexus 9504 NX-OS Mode Switch Hardware Installation Guide
11
Preparing the Site
Planning for Power Requirements
