Chapter 4 Connecting the Cisco RPS
Connecting Routers and the Cisco MC3810 Concentrator
4-16
Cisco Redundant Power System Hardware Installation Guide
OL-3654-01
Figure 4-21 Cisco MC3810 Multiservice Concentrator Rear Panel
Step 3
Connect the other end of the one-to-one or Y-cable to the rear panel connector on
the Cisco RPS, as shown in Figure 4-22 and Figure 4-23.
Figure 4-22 Connecting a One-to-One Cable for Quasi-Redundant Power
12212
Cisco RPS
connector
On/off switch
SERIAL 1
CONSOLE AUX
P
O
E
R
W
A
V
M
1
2
3
4
5
6
SERIAL 0
ETHERNET 0
29090
AC INPUT 1
100-200 V~ 50/60 Hz
10-5 A 1000 W
AC INPUT 2
100-200 V~ 50/60 Hz
10-5 A 1000 W
DC OUTPUT 1
DC OUTPUT 2
DC OUTPUT 3
DC OUTPUT 4
