Cisco RV180 Administration Guide

Configuring the Firewall
Firewall Configuration Examples
Cisco RV180/RV180W Administration Guide 103
4
Create an outbound access rule with the following parameters:
Create an inbound access rule with the following parameters:
Parameter Value
Connection Type Outbound
Action Block by Schedule
Schedule Weekend
Service HTTP
Source IP Address Range
Start starting IP address
Finish ending IP address
Destination IP Any
Rule Status Enabled
Parameter Value
Connection Type Inbound
Action Block by Schedule
Schedule Weekend
Service All Traffic
Source IP Any
Rule Status Enabled

Cisco RV180 Specifications

General

WAN Ports	1
LAN Ports	4
VPN Support	Yes
Wireless Support	No
Firewall	Yes
Device Type	VPN Router
VPN Tunnels	10
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Encryption	3DES, AES
VPN Protocols	IPSec
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Humidity	10% to 85% non-condensing
Dimensions	130 x 130 x 35 mm
Weight	0.28 kg
