Before you begin
Configure SNMP for one of the instances. See SNMP.
Procedure
Step 1 From Devices > Device Management, click Manage in the Chassis column or click Edit ( ).
Figure 36: Manage Chassis
The Chassis Manager page opens for the chassis to the Summary page.
Step 2 Click System Configuration.
Step 3 Click SNMP, and choose the instance from the drop-down list.
Figure 37: SNMP
SNMP on the chassis will be accessible from the selected instance.
Step 4 Click Save.
Step 5 Deploy the chassis configuration.
Import or Export the Chassis Configuration
You can use the configuration export feature to export an XML file containing chassis configuration settings
to your local computer. You can later import that configuration file to quickly apply the configuration settings
to your chassis to return to a known good configuration or to recover from a system failure. You can also
import the chassis configuration to a new chassis, for example for an RMA, as long as the prerequisites are
met.
When exporting, only chassis configurations are exported; instance configuration settings are not exported.
Instances need to be backed up separately using the device backup/restore feature.
When importing, all existing configurations on the chassis will be replaced by the configuration in the import
file.
Multi-Instance Mode for the Secure Firewall 3100
39
Multi-Instance Mode for the Secure Firewall 3100
Import or Export the Chassis Configuration
