Cisco SG350-10P Administration Guide

VLAN Management
VLAN Groups
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 247
12
Workflow
To define a protocol-based VLAN group:
1. Define a protocol group (using the Protocol-Based Groups page).
2. For each required interface, assign the protocol group to a VLAN (using Protocol-Based
Groups to VLAN page). The interfaces must be in General mode and cannot have a
Dynamic VLAN (DVA) assigned to it.
Protocol-Based Groups
To define a set of protocols.
STEP 1 Click VLAN Management > VLAN Groups > Protocol-Based Groups.
The Protocol-Based Groups Page contains the following fields:
• Encapsulation—Displays the protocol on which the VLAN group is based.
• Protocol value (Hex)—Displays the protocol value in hex.
• Group ID—Displays the protocol group ID to which the interface is added.
STEP 2 Click the Add Button.
STEP 3 Enter the following fields:.
• Encapsulation—Protocol Packet type. The following options are available:
- Ethernet V2—If this is selected, select the Ethernet Type.
- LLC-SNAP (rfc1042)—If this is selected, enter the Protocol Value.
- LLC—If this is selected, select the DSAP-SSAP Values.
• Ethernet Type—Select the Ethernet type for Ethernet V2 encapsulation. This is the
two-octet field in the Ethernet frame used to indicate which protocol is encapsulated in
the payload of the Ethernet packet) for the VLAN group
• Protocol Value—Enter the protocol for LLC-SNAP (rfc 1042)encapsulation.
• Group ID—Enter a protocol group ID.
STEP 4 Click Apply. The Protocol Group is added, and written to the Running Configuration file.

Cisco SG350-10P Specifications

General

Product Name	Cisco SG350-10P
Category	Switch
Ports	10
PoE Ports	8
PoE Power Budget	62W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Layer	Layer 3
Power Supply	Internal
Relative Humidity	10% to 90% non-condensing
MAC Address Table Size	8K
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Operating Altitude	Up to 3, 000 meters
