Cisco TelePresence MX700 Administrator's Guide

D15119.02 MX700 and MX800 Administrator Guide TC7.2, AUGUST 2014. www.cisco.com — Copyright © 2014 Cisco Systems, Inc. All rights reserved.
16
Cisco TelePresence MX700 and MX800 Administrator Guide
Configuration
System Configuration
System Status
Local Contents Management
Personalization
The interactive menu
The web interface provides access to tasks and
configurations. They are available from the main menu, which
appears near the top of the page when you have signed in.
When you hover the mouse over an item in the main menu,
you can navigate to its related sub-pages.
Main menu
Hover the mouse over a main menu item in
order to see the titles of the related sub-pages.
Click a sub-page’s title to open it. Click the
main menu item itself if there are no sub-
pages. Only pages that the user has access
rights for are shown
*
.
Click Home to return to the System Information
page.
Call Control Maintenance
Software Upgrade
Backup and Restore
System Recovery
Restart
Diagnostics
Troubleshooting
Peripherals
User Administration
Sign In Banner
Startup Scripts
Sub-pages
*
You can read more about user administration, user roles and access
rights in the ► User administration section.
API
Call History
Security
Log Files
User Interface Screenshots
Contents
Introduction
Web interface
System settings
Setting passwords
Appendices
Web interface

Cisco TelePresence MX700 Specifications

General

Product Type	Video conferencing system
Frame Rate	Up to 60 fps
Display	Dual 55-inch LCD
Audio	Integrated speakers and microphones
Video Standards	H.264
Network	Ethernet
Connectivity	HDMI, USB
Control	Touch 10 control unit
Video Resolution	1080p at 60 fps
Zoom	12x optical zoom
Codec	H.264
Network Protocols	SIP
Power Consumption	300W
Weight	90 kg
