10
Remove support handles
78-100574-02A0 | 2016 JUNE | © 2016 Cisco Systems, Inc. All rights reserved.
Installation guide for Cisco TelePresence MX800 Dual - Floor stand
Page 15
Unscrew the screws (4 × M4x8)
and remove the support handles.
1
Unscrew the screws (2 × M4x8)
and remove the brackets that the
support handles were fastened to.
2
