Cisco Telepresence MX800 - Assemble Floor Stand

2
Assemble floor stand
B, I
78-100574-02A0 | 2016 JUNE | © 2016 Cisco Systems, Inc. All rights reserved.
Installation guide for Cisco TelePresence MX800 Dual - Floor stand
Page 6
Fasten the upper and lower center parts
simultaneously, first one side; then the
other side.
Six screws from the back
and four from the top.
10 × M6x12, countersunk
8 × M6x12, countersunk
