1
Remove covers from floor stand parts
A
78-100574-02A0 | 2016 JUNE | © 2016 Cisco Systems, Inc. All rights reserved.
Installation guide for Cisco TelePresence MX800 Dual - Floor stand
Page 5
Set aside the covers. They will be
replaced when the system is fully
assembled and tested (step 20).
Front

Other manuals for Cisco Telepresence MX800

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco Telepresence MX800 and is the answer not in the manual?

Cisco Telepresence MX800 Specifications

General IconGeneral
Pan range-90 - 60 °
Product typeVideo conferencing service management system
Product colorWhite
Wall mountableYes
Tilt angle range-14 - 12 °
Number of persons- person(s)
Aspect ratio16:9
Maximum frame rate60 fps
Supported video modes720p, 1080p
Video formats supportedH.261, H.263, H.264, H.265
Resolution at capture speed1920x1080@60fps
Supported graphics resolutions352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel- MP
Sensor type-
Digital zoom2 x
Optical zoom10 x
Image sensor size- \
Closest focusing distance1 m
Ethernet LAN data rates10, 100, 1000 Mbit/s
Display diagonal70 \
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (max)591 W
Power consumption (typical)571 W
