Cisco Telepresence MX800 Installation Guide

78-100574-02A0 | 2016 JUNE | © 2016 Cisco Systems, Inc. All rights reserved.
Installation guide for Cisco TelePresence MX800 Dual - Floor stand
Page 2
Manpower
We recommend four people working together
to mount the system. Follow local regulations.
Dimensions
Height: 1818 mm / 71.6 in.
Width: 3169 mm / 124.8 in.
Depth: 156 or 215 mm / 6.2 or 8.5 in. (wall secured)
920 mm / 36.3 in. (free standing)
Weight: 238 kg / 525 lb
4
Floor stand secured to the wall
This guide covers the floor stand mounted MX800 Dual
in either the free standing or wall secured configurations.
Free standing floor stand
Room setup
Explore the Cisco Project Workplace to find
inspiration and guidelines when preparing your
office or meeting room for video conferencing,
http://www.cisco.com/go/projectworkplace
Documentation
Cisco Spark: Visit the Cisco Spark help site to
find more information about Spark registered
room systems, http://help.ciscospark.com
Other services: Visit the Cisco web site
to find user guides and compliance and
safety information for the video system,
http://www.cisco.com/go/mx-docs

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
