18
Connect external cables (page 2 of 2)
I, J
78-100574-02A0 | 2016 JUNE | © 2016 Cisco Systems, Inc. All rights reserved.
Installation guide for Cisco TelePresence MX800 Dual - Floor stand
Page 25
Touch 10
3
AP
3
The Ethernet socket is behind the lid at the rear of
Touch 10. Use one of the provided PoE rated CAT 5e
Ethernet cables, 12.5 m or 4 m, flat.
Route the cables down,
and put them behind the
hooks in the floor stand.
