Chapter 7 Cisco TrustSec Command Summary
cts role-based
The vlan-ids argument can be a single VLAN ID, a list of VLAN IDs, or VLAN ID ranges. Separate
multiple entries with a hyphen “-” or a comma “,”.
The keyword all is equivalent to the full range of VLANs supported by the platform (For example, the
Catalyst 6500 VLAN range is 1–4094). Issuing multiple commands has an additive effect. SGACLs are
enforced on all the VLANs of all the lists specified. The keyword all is not preserved in the nonvolatile
generation (NVGEN) process.
Note SGACL enforcement is not enabled by default on VLANs. The cts role-based enforcement vlan-list
command must be issued to enable SGACL enforcement on VLANs.
Note When a VLAN in which a role-based access control (RBAC) is enforced has an active SVI, the RBAC
is enforced for both Layer 2 and Layer3 switched packets within that VLAN. Without an SVI, the RBAC
is enforced only for Layer 2 switched packets, because no Layer 3 switching is possible within a VLAN
without an SVI.
Flexible Net Flow
Flexible NetFlow can account for packets dropped by SGACL enforcement when SGT and DGT flow
objects are configured in the flow record with the standard 5-tuple flow objects
Use the flow record
and flow exporter global configuration commands to configure a flow record, and
a flow exporter, then use the flow monitor command add them to a flow monitor. Use the show flow
show commands to verify your configurations.
To collect only SGACL dropped packets, use the [no] cts role-based {ip | ipv6} flow monitor dropped
global configuration command.
For Flexible NetFlow overview and configuration information, see the following documents:
Getting Started with Configuring Cisco IOS Flexible NetFlow
http://www.cisco.com/en/US/docs/ios/fnetflow/configuration/guide/get_start_cfg_fnflow.html
Cisco IOS Flexible NetFlow Configuration Guide, Release 15.0SY
http://www.cisco.com/en/US/docs/ios-xml/ios/fnetflow/configuration/15-0sy/fnf-15-0sy-book.html
Examples In the following example, a Catalyst 4500 series switch binds host IP address 10.1.2.1 to SGT 3 and
10.1.2.2 to SGT 4, then verifies with a show command. These bindings will be forwarded by SXP to an
SGACL enforcement switch.
cat4k# (config)# cts role-based sgt-map host 10.1.2.1 sgt 3
cat4k(config)#cts role-based sgt-map host 10.1.2.2 sgt 4
cat4k# show cts role-based sgt-map all
Active IP-SGT Bindings Information
IP Address SGT Source
============================================
10.1.2.1 3 CLI
10.1.2.2 4 CLI
IP-SGT Active Bindings Summary
============================================
Total number of CLI bindings = 2
Total number of active bindings = 2
