DescriptionProduct ID
10GBASE-AOC SFP+ cable 10 meterSFP-10G-AOC10M
The maximum length of fiber optic runs is limited to 300 meters. This is imposed by our use of
802.3X/802.1Qbb Priority Pauses. SFP-10G-LR is supported between fabric interconnect and FEX, but the
300 m limit still applies.
Note
QSFP Transceivers and Cables
The Cisco UCS 6300 Series Fabric Interconnects support Cisco 40GGBASE Quad Small Form Factor (QSFP)
transceiver modules.
Table 5: Supported QSFP Transceivers and Cables
DescriptionModel
40GBASE-SR4 QSFP module (multimode fiber [MMF]), 100 meterQSFP-40G-SR4
40GBASE-SR4 QSFP module (multimode fiber [MMF]), 100 meterQSFP-40G-SR4-S
40GBASE Extended CSR4 QSFP module (MMF), 300 meterQSFP-40G-CSR4
Cisco 40GBASE-LR4 QSFP+ transceiver module for SMF, duplex LC
connector
QSFP-40G-LR4
Cisco 40GBASE-LR4 QSFP+ transceiver module for SMF, duplex LC
connector
QSFP-40G-LR4-S
Cisco QSFP40G BiDi Short-reach transceiverQSFP-40G-SR-BD
Cisco 40G Line Extender for FEXFET-40G
Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ active direct-attached
breakout cable, 7 meter
QSFP-4x10G-AC7M
Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ active direct-attached
breakout cable, 10 meter
QSFP-4x10G-AC10M
Cisco 40GBASE-CR4 SFP+ passive direct-attach copper cable, 1 meterQSFP-H40G-CU1M
Cisco 40GBASE-CR4 SFP+ passive direct-attach copper cable, 3 meterQSFP-H40G-CU3M
Cisco 40GBASE-CR4 SFP+ passive direct-attach copper cable, 5 meterQSFP-H40G-CU5M
Cisco 40GBASE-CR4 SFP+ active direct-attach copper cable, 7 meterQSFP-H40G-ACU7M
Cisco 40GBASE-CR4 SFP+ active direct-attach copper cable, 10 meterQSFP-H40G-ACU10M
Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ passive direct-attach
copper transceiver assembly, 1 meter
QSFP-4SFP10G-CU1M
Cisco UCS 6300 Series Fabric Interconnect Hardware Installation Guide
14
Product Overview
QSFP Transceivers and Cables
