Removing a Cable from a Transceiver
To prevent damage to the copper cables, do not place more tension on them than the rated limit and do not
bend to a radius of less than 1 inch if there is no tension in the cable, or 2 inches if there is tension in the cable.
Caution
When pulling a cable from a transceiver, grip the body of the connector. Do not pull on the jacket sleeve,
because this action can compromise the fiber-optic termination in the connector.
Caution
If the cable cannot be easily removed, ensure that any latch present on the cable has been released before
continuing.
Caution
Procedure
Step 1 Attach an ESD wrist strap and follow the instructions for its use.
Step 2 Press the release latch on the cable, grasp the connector near the connection point, and gently pull the connector
from the transceiver.
Step 3 Insert a dust plug into the cable end of the transceiver.
Step 4 Insert a dust plug onto the end of the cable.
Connecting to a Fibre Channel Port
Installing or Removing SFP+ Transceivers
Installing an SFP Transceiver
Excessively removing and installing an SFP transceiver can shorten its life. Do not remove and install
transceivers more often than necessary. We recommend that you disconnect cables before installing or removing
SFP transceivers to prevent damage to the cable or transceiver.
Caution
Procedure
Step 1 Attach an ESD wrist strap and follow the instructions for its use.
Step 2 Remove the dust cover from the port cage.
Step 3 Remove the dust cover from the port end of the transceiver.
Cisco UCS 6300 Series Fabric Interconnect Hardware Installation Guide
50
Connecting the Cisco UCS 6300 Series Fabric Interconnect
Removing a Cable from a Transceiver
