Procedure
Step 1 Compare the shipment to the equipment list provided by your customer service representative and verify that
you have received all items, including the following:
• Grounding lug kit
• Rack-mount kit
• ESD wrist strap
• Cables with connectors
• Any optional items ordered
Step 2 Check for damage and report any discrepancies or damage to your customer service representative. Have the
following information ready:
• Invoice number of shipper (see packing slip)
• Model and serial number of the damaged unit
• Description of damage
• Effect of damage on the installation
Installing the Cisco UCS Chassis or UCS Chassis in a Cabinet
or Rack
This section describes how to use the rack-mount kit provided with the chassis to install Cisco UCS into a
cabinet or rack that meets the requirements described in Cabinet and Rack Requirements, on page 20. All
Cisco UCS Fabric Interconnects use the same installation procedure.
If the rack is on wheels, ensure that the brakes are engaged or that the rack is otherwise stabilized.
Caution
This table lists the items contained in the rack-mount kit provided with the chassis.
Table 7: Chassis Rack-Mount Kit
Part DescriptionQuantity
Rack-mount brackets2
M4x0.7 x 8-mm Phillips countersink screws12
10-32 cage nuts10
10-32 x 3/4-inch Phillips pan-head screws10
Cisco UCS 6300 Series Fabric Interconnect Hardware Installation Guide
23
Installing the Cisco UCS 6300 Series Fabric Interconnect
Installing the Cisco UCS Chassis or UCS Chassis in a Cabinet or Rack
