DescriptionLED State
Administrative (software shutdown)Yellow
L1 and L2 Port LEDs
The L1 and L2 port LED states are listed below.
DescriptionLED StateLED Position
No linkOffLeft
Physical linkSolid greenLeft
No activityOffRight
ActivityBlinking greenRight
Supported Transceivers
The Cisco UCS 6300 Series Fabric Interconnects support SFP+ Ethernet transceivers, SFP transceivers, SFP+
transceivers, SFP+ copper twinax cables with integrated transceivers, SFP Fibre Channel transceivers, QSFP
transceivers, and QSFP cables. Except where noted, both the UCS 6332 Fabric Interconnect and the UCS
6332-16UP Fabric Interconnect support all the transceivers listed in this section.
On the Cisco UCS 6332 Fabric Interconnect, all 1-Gigabit and 10-Gigabit transceivers and twinax cables
must use a QSA module (CVR-QSFP-SFP10G) to operate in a 40-Gbps QSFP+ port. In addition, the QSA
module is required for a 40-Gbps QSFP+ port to operate at 1 Gbps or 10 Gbps.
On the Cisco UCS 6332-16UP Fabric Interconnect, all 1-Gigabit and 10-Gigabit transceivers, Fibre Channel
transceivers, and twinax cables must use a QSA module (CVR-QSFP-SFP10G) to operate in ports 17–40 (the
40-Gbps QSFP+ ports). Ports 1–16 operate as SFP+ universal ports that are capable of operating at 1- or
10-Gbps fixed Ethernet or 4-, 8-, or 16-Gbps Fibre Channel ports and do not need a QSFP to SFP+ adapter.
In addition, the QSA module is required for a 40-Gbps QSFP+ port to operate at 1 Gbps or 10 Gbps.
SFP 1-Gigabit Transceivers
The SFP 1-Gigabit Ethernet transceiver module is a bidirectional device with a transmitter and receiver in the
same physical package.
Table 3: Supported SFP Optical Transceivers
DescriptionModel
1000BASE-T standardGLC-T
1000BASE-SX short wavelength; with MDOMGLC-SX-MMD
1000BASE-T SFP (NEBS 3 ESD)—supported only
on the UCS 6332-16UP Fabric Interconnect
SFP-GE-T
Cisco UCS 6300 Series Fabric Interconnect Hardware Installation Guide
12
Product Overview
L1 and L2 Port LEDs
