Power Specifications
Cisco UCS 6300 Fabric Interconnects support AC, DC, or HVDC power supplies. You must use identical
power supplies—either two AC, two DC, or two HVDC power supplies— with the fabric interconnect. In
addition, if you use DC or HVDC power supplies, you must use two corresponding DC or HVDC power
cords.
You cannot mix power supply types in a Cisco 6300 Series Fabric Interconnect.
Note
Table 10: Specifications for the Cisco UCS 6300 Series AC Power Supply(UCS-PSU-6332-AC)
Cisco UCS 6300 Series Fabric InterconnectAC Power Supply Properties
650 WMaximum output per power supply
100 to 240 VACInput voltage
7.6 A @ 100 VAC
3.65 A @ 208 VAC
Maximum AC input current
12 ms @50% loadMaximum holdup time
12 VDCPower supply output voltage
12 VDCPower supply standby voltage
YesRoHS compliance
YesHot swappable
Climate Savers Platinum Efficiency (80Plus Platinum
Certified)
Efficiency rating
Table 11: Specifications for the Cisco UCS 6300 Series DC Power Supply (UCS-PSU-6332-DC)
Cisco UCS 6300 Series Fabric InterconnectDC Power Supply Properties
930 WMaximum output per power supply
-48 VDCInput voltage
23 A maximum @ -48 VDCMaximum HVDC input current
8 ms @ 50% loadMaximum holdup time
12 VDCPower supply output voltage
12 VDCPower supply standby voltage
YesRoHS compliance
Cisco UCS 6300 Series Fabric Interconnect Hardware Installation Guide
56
Technical Specifications
Power Specifications

Cisco UCS 6332 Specifications

General

Switching Capacity	2.56 Tbps
Form Factor	1 RU
Product Type	Fabric Interconnect
Input Voltage	100-240 VAC
Management	Cisco UCS Manager
Power Supply	Dual hot-swappable power supplies
Jumbo Frame Support	Supported
Fans	4 hot-swappable fans
Latency	Less than 1 microsecond
