Cisco UCS C200 M2 - Page 18

Cisco UCS C200 M2 High-Density SFF Drive Rack-Mount Server
18
CONFIGURING the SERVER
(3) Optional RAID configuration
■ Select one of the RAID configuration options listed in Table 5.
Caveats
■ The two optional RAID controllers are half-height PCIe cards. If you choose one of these
optional cards, only the full-height PCIe card slot will be available for adding an optional
PCIe card.
■ If you choose the mezzanine card, both the half-height and full-height PCIe card slots are
still available for adding optional PCIe cards.
■ You can choose only one RAID controller (integrated controller, plug-in PCIe controller, or
mezzanine card controller).
■ You can choose an optional RAID configuration (RAID 0, 1, 5, 1E, 6, or 10), which is
preconfigured at the factory. If you do not choose a RAID configuration, the disks will be
configured as a JBOD.
NOTE: If an optional RAID configuration is not chosen, the disks will be configured as
a JBOD.
