Figure 33: PCIe Riser Alignment Features
Riser alignment features in chassis2Blue riser handle1
e) Carefully push down on both ends of the PCIe riser to fully engage its two connectors with the two sockets on the
motherboard.
f) Replace the top cover to the server.
g) Replace the server in the rack, replace cables, and then fully power on the server by pressing the Power button.
Cisco Virtual Interface Card (VIC) Considerations
This section describes VIC card support and special considerations for this server.
If you use the Cisco Card NIC mode, you must also make a VIC Slot setting that matches where your VIC is
installed. The options are Riser1, Riser2, and Flex-LOM. See NIC Mode and NIC Redundancy Settings for
more information about NIC modes.
Note
If you want to use the Cisco UCS VIC card for Cisco UCS Manager integration, see also the Cisco UCS
C-Series Server Integration with Cisco UCS Manager Guides for details about supported configurations,
cabling, and other requirements.
Table 8: VIC Support and Considerations in This Server
Minimum Cisco
IMC Firmware
Primary Slot For
Cisco Card NIC
Mode
Primary Slot For
Cisco UCS Manager
Integration
Slots That
Support VICs
How Many
Supported in
Server
VIC
3.1(1)PCIe 1PCIe 1PCIe 1
PCIe 2
2 PCIeCisco UCS VIC 1385
UCSC-PCIE-C40Q-03
Maintaining the Server
59
Maintaining the Server
Cisco Virtual Interface Card (VIC) Considerations

Cisco UCS C220 M5 Specifications

General

Processor cache	22 MB
Processor model	6130
Execute Disable Bit	Yes
Processor frequency	2.1 GHz
Processor manufacturer	Intel
Processor boost frequency	3.7 GHz
Number of processors installed	2
On-board graphics card	-
Memory slots	24
Internal memory	64 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	128 GB
SSD interface	Serial Attached SCSI (SAS)
Optical drive type	No
Supported HDD sizes	2.5, 3.5 \
Supported SSD sizes	2.5\
Total storage capacity	32 GB
Maximum storage capacity	- TB
Chassis type	Rack (1U)
Power supply	700 W
Intel TSX-NI version	1.00
